Beskrivning
MM & MC RIAA steg i solid Aluminium. Extern nätdel. Automatisk impedansmatchning. MM/MC switch med enkel knapptryckning på undersidan.
MM & MC RIAA steg i solid Aluminium.
All of which adds up to the basic V2 being the perfect all-rounder for both audiophiles and music lovers.
EGENSKAPER
* MODE: MM/MC (Subsonic filter switchable)
* AMPLIFICATION @ 1 KHZ: +46 dB (MM mode)
+66 dB (MC mode)
* INPUT IMPEDANCE: 47 kOhm / 270 pF / MM mode
500 Ohm / 270 pF / MC mode
* MM / MC INPUT: switchable (at bottom)
* RIAA: 75 ?s / 318 ?s / 3180 ?s, 2 passive filter
RIAA ACCURACY: ± 0.10 dB
* THD: < 0.002% (IEC A)
* SIGNAL TO NOISE RATIO: -72 db (MM mode)
-67 dB (MC mode)
* CHANNEL SEPARATION: > 90 dB (@ 1 kHz)
* MAX. OUTPUT VOLTAGE: >10 V (@ 1 kHz)
* SUBSONIC FILTER: 20 Hz (18 dB / Oct.; switchable on bottom panel, on each channel)
* POWER CONSUMPTION: Max. consumption in operation: 3 watts
Standby mode: <0.3 watts
* POWER SUPPLY: ± 18 V DC (external power supply, 1.4m cable length)
* OUTPUT CONNECTIONS: Unbalanced (RCA)
* TOTAL WEIGHT: Approx. 1.2 kg (Preamp and power supply)
Crosstalk: > 90 dB
Frequency: 10Hz – 100kHz
Max. output voltage: 11 V (1 kHz)
Operation voltage: ± 25 V DC
Output connections: Unbalanced RCA
Weight: 1.5 kg Dimensions (W/D/H in inches): 4.0 x 6.5 x 2.4 Dimensions (W/D/H in mm): 102 x 165 x 60
-2Års Garanti.
