Beskrivning
Van Den Hul The Digi-Coupler 75 ohm är en prisvärd Coaxialkabel av deras instegsmodell med maximal prestanda för pengarna.
The Digi-Coupler 75 ohm håller konstant 75 ohm för bästa prestanda.
EGENSKAPER
material | Silverplated Copper OFC |
product category | audio video – 75 Ohm |
product category | interconnect – Unbalanced, Digital |
product category | video |
cable type | Triaxial, Superscreened |
conductor material | Core: High purity Matched Crystal OFC Intermediate conductor and Screen: High purity dense Silver coated high purity Matched Crystal OFC |
design purpose | Highest quality level: Digital audio (SPDIF) interconnect; Interconnect for Video and HF signal transport; Unbalanced measuring equipment interconnect; General purpose and hometheatre unbalanced interlink |
eff conductor | Core: 0.283 mm² / Core: AWG 22.6 / Core: 1; Intermediate conductor: Al foil + 128 + Al foil + 128; Screen: Al foil + 192 |
external diameter | 8.2 mm. |
jacket colors | Gold tone |
resistance | Core: 5.92 Ohm/100 m.; Intermediate conductor: 0.814 Ohm/100 m.; Screen: 0.747 Ohm/100 m. |
capacitance | Core-Intermediate conductor: 56.2 pF/m.; Intermediate conductor-Screen: 470 pF/m. |
characteristic impedance | 75 Ohm |
insulation |
Core: PE foam; Intermediate conductor: PE; Jacket: HULLIFLEX ® / 300 Vrms min. |
connector types |
Our BNC type BNC – 9.0 and our RCA type C – 8.4; Custom mountable on ordered lengths. |
