Rotel RMB-1555 – 5-kanals Slutsteg

Beskrivning

Rotel RMB-1555 är ett mycket strömstarkt och välljudande 5kanals slutsteg.

-Klass A/B -5*120Watt

The RMB-1555 is a remarkable multichannel amplifier with power output conservatively rated at 120 watts per channel into 8 ohms (all channels driven!). With all but the most demanding speakers located in extraordinarily large rooms, the RMB-1555 exerts the kind of precise control that presents both nuance and bombast correctly from the faintest flute overtones to the subterranean rumble of an approaching apocalypse.

The RMB-1555 employs high a current, toroidal transformer matched to discrete output transistors with their higher thermal stability and freedom from the designed-in compromises that characterize their integrated circuit cousins.

The Class AB amplifier configuration assures the best balance between power output and thermal efficiency.

EGENSKAPER

• • Continuous Power Output (20-20kHz, < 0.03%, 8 ohms)120 watts/channel 5 channels dirven

• • Total Harmonic Distortion (20Hz-20kHz, 8 ohms)< 0.03%

• • Intermodulation Distortion (60Hz : 7 kHz, 4:1)< 0.03%

• • Frequency Response (+0.5, –3 dB) 10Hz – 100kHz

• • Damping Factor (20-20,000Hz, 8 ohms)180

• • Speaker Impedance 4 ohms minimum

• • Signal to Noise Ratio (IHF A network)116 dB

• • Input Impedance/Sensitivity 12k ohms/1.5 volt

• • Gain 26.5 dB

• • Power Requirements – European version 230 volts, 50Hz

• • Power Consumption 650 watts

• • Width x Height x Depth 431 x 188 x 454mm 17 x 7 1/2 x 17 7/8 in

• • Front Panel Height 4U / 176.8mm / 7 in W eight (net) 21.8kg / 48.1 lb

• • 2Års Garanti
